Fortinet FortiDDoS 1500E – security appliance Device Type Security appliance Form Factor External – 2U Hard Drive 960 GB x 1 Data Link Protocol Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet Performance Throughput: 35 Gbps ? Packet filter throughput: 38 Gbps ? Latency: 50 ?s Capacity Simultaneous connections: 12000000 Power AC 120/230 V (50/60 Hz) Power Redundancy Yes Dimensions (WxDxH) 17.2 in x 22 in x 3.5 in Weight 44.09 lbs

EXTENDED SPECIFICATIONS

General Device Type Security appliance Height (Rack Units) 2U Width 17.2 in Depth 22 in Height 3.5 in Weight 44.09 lbs Processor / Memory / Storage Hard Drive SSD 960 GB x 1 Networking Form Factor External Connectivity Technology Wired Data Link Protocol Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet Network / Transport Protocol TCP/IP, UDP/IP Remote Management Protocol SNMP 2, SNMP 3, HTTP, CLI, ICMP, TACACS+, LDAP, RADIUS Performance Throughput: 35 Gbps ? Packet filter throughput: 38 Gbps ? Latency: 50 ?s Capacity Simultaneous connections: 12000000 Features Packet filtering, DDos attack prevention, Access Control List (ACL) support Authentication Method RADIUS, LDAP Expansion / Connectivity Interfaces 8 x 1Gb Ethernet/10Gb Ethernet – SFP+ (WAN) ? 8 x 1Gb Ethernet/10Gb Ethernet – SFP+ ? 2 x 40Gb Ethernet – QSFP+ (WAN) ? 2 x 40Gb Ethernet – QSFP+ ? 2 x 1000Base-T (management) – RJ-45 ? 1 x console – RJ-45 ? 1 x USB 3.0 – Type A ? 8 x bypass (optical) Miscellaneous Compliant Standards UL, VCCI, C-Tick, cUL, CB, FCC Part 15 A Power Power Device Internal power supply – hot-plug Installed Qty 2 Max Supported Qty 2 Power Redundancy Yes Voltage Required AC 120/230 V (50/60 Hz) Power Consumption Operational 1320 Watt Environmental Parameters Min Operating Temperature 32 ?F Max Operating Temperature 104 ?F Humidity Range Operating 5 – 95% (non-condensing)
