| General |
| Switch – 24 ports – L3 – managed – stackable | | Rack-mountable 1U | | Gigabit Ethernet | | 24 x Gigabit SFP | | Switching capacity: 128 Gbps ¦ Stacking bandwidth: 480 Gbps ¦ Forwarding rate: 154.76 Mpps | | IPv4 routing table entries: 32000 ¦ IPv6 routing table entries: 16000 ¦ Flexible NetFlow entries: 64000 ¦ VLAN IDs: 4000 ¦ Switched virtual interfaces (SVIs): 2000 | | 32000 entries | | 9198 bytes | | OSPF, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng | | SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF | | 128-bit AES | | Trunking, full duplex mode, Weighted Random Early Detection (WRED), Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), Remote Switch Port Analyzer (RSPAN), Management Information Base (MIB), Cisco StackWise-480 technology, Cisco StackPower technology, Flexible NetFlow (FNF), 802.1x authentication, 16MB packet buffer, FTP client, 3 fans, Control plane protection (CoPP), Source-Specific Multicast (SSM), integrated Wireshark, VLAN Double Tagging (Q-in-Q), Private VLAN | | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s | | 8 GB | | 16 GB | | Status |
|
| Expansion / Connectivity |
| 24 x Gigabit LAN SFP ¦ 1 x USB 2.0 | | 1 (total) / 1 (free) x expansion slot |
|
| Power |
| Internal power supply – hot-plug | | 1 | | 2 | | Yes | | 715 Watt | | AC 120/230 V (50 – 60 Hz) |
|
| Miscellaneous |
| 284,130 hours | | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, EN 55022 Class A, FCC CFR47 Part 15 A, EN 300 386, TVCN 7317, VCCI V-3/2009 Class A, CAN/CSA-C22.2 No. 60950-1 |
|
| Software / System Requirements |
| Cisco ONE StealthWatch License Term – 25 Flow Licenses, 25 x Cisco ONE ISE BASE Tracker Licenses Term (5 years), 25 x Cisco ONE ISE PLUS Tracker Licenses Term (5 years), Network Plug-n-Play License | | Cisco IOS Universal |
|
| Dimensions & Weight |
| 17.5 in | | 19.2 in | | 1.7 in | | 16.84 lbs |
|
| Manufacturer Warranty |
| Limited warranty – replacement – lifetime – response time: next business day ¦ Technical support – consulting – 90 days |
|
| Environmental Parameters |
| 23 Degree Fahrenheit | | 113 Degree Fahrenheit | | 5 – 90% (non-condensing) | | -40 Degree Fahrenheit | | 158 Degree Fahrenheit | | 5 – 90% (non-condensing) |
|
