JE074B – HPE FlexNetwork 5120-24G SI – Switch – L3 – managed – 24 – 10/100/1000 – 4 – Gigabit SFP – rack-mountable.

MPN: JE074B | UPC: 0 889894168733 | CONDITION: New

Price of JE074B

$1,244.00

*Including free ground shipping to USA

Availability: 4 units in stock

Our Shipping Partners

Standard shipping is 5-7 Business Days

100% Secure Payments

Payments processed via STRIPE

Secure Payments

Pay Securely

Fast Shipping

Overnight Available

Save Big

Affordable Prices

9-5 Support

Call Us for Help

How our customers express their love

Product Details

HPE 5120-24G SI – Switch – L3 – managed – 24 x 10/100/1000 + 4 x Gigabit SFP – rack-mountable

The HPEFlexNetwork 5120 SI Switch Series are Layer 2 switches that support stacking, static Layer 3 routing, PoE+, ACLs and IPv6. They are campus switches ideal for medium and large enterprise networks. HPEIntelligent Resilient Framework (IRF) technology creates a virtual fabric by managing four switches as one logical device, which increases network resilience, performance, and availability while reducing operational complexity. The FlexNetwork 5120 SI Switch Series can be managed with HPEIntelligent Management Center (IMC) Software for a single view of your entire network.

WHAT’S IN THE BOX – (1) HPE5120 24G SI Switch

Managed Access Layer Switches

The HPEFlexNetwork 5120 SI Switch Series is ideal for medium and large enterprises looking for a traditional, scalable, fully managed Layer 2 access switch with static IP routing, PoE+, ACLs, IPv6, and support for stacking.
The HPEIntelligent Resilient Framework (IRF) virtualizes up to four physical switches into one logical device for simpler, flatter, more agile networks.
PoE+ models support up to 370 W of PoE/PoE+ power for phones, cameras and wireless access points; up to 720 W available on the 24-port model with optional accessories.
Right size deployment with 8-, 16-, 24-, and 48-port gigabit Ethernet models that include up to 4 SFP ports for fiber uplinks.

Advanced Quality of Service (QoS)

The HPEFlexNetwork 5120 SI Switch Series delivers a better application experience with classifier-based QoS using multiple match criteria based on Layer 2, 3, and 4 information; applies QoS policies such as setting priority level and rate limit to selected traffic on a per port basis.
Network traffic prioritization with multiple congestion methods include: strict priority (SP) queuing, SDWRR, and SP+WRR.

Security Control

The HPEFlexNetwork 5120 SI Switch Series supports hardware-based wire-speed access control lists (ACLs) for enhanced security and ease of administration without impacting network performance.
RADIUS/HWTACACS, SSL, Port Security, and 802.1x and MAC-based authentication deliver enhanced security.

Single View of the Network

The HPEFlexNetwork 5120 SI Switch Series can be seamlessly managed with HPEIntelligent Management Center (IMC) Software to provide end-to-end network transparency with consistent network experience through comprehensive configuration, compliance and policy management.
Remote Network Monitoring (RMON) provides advanced monitoring and reporting capabilities for statistics, history, alarms and events.

MAIN SPECIFICATIONS

Product DescriptionHPE5120-24G SI – switch – 24 ports – managed – rack-mountable
Device TypeSwitch – 24 ports – L3 – managed
Enclosure TypeRack-mountable 1U
SubtypeGigabit Ethernet
Ports24 x 10/100/1000 + 4 x Gigabit SFP
PerformanceLatency (1000Base-T): 3 ?s ? Throughput: up to 41.7 Mpps ? Routing/switching capacity: 56 Gbps
CapacityVirtual interfaces (VLANs): 4094 ? IPv4 routing table entries: 32
MAC Address Table Size8192 entries
Jumbo Frame Support10KB
Routing ProtocolOSPF, RIP, IGMP, static IPv4 routing, static IPv6 routing
Remote Management ProtocolSNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTPS, CLI
FeaturesFlow control, DHCP support, VLAN support, auto-uplink (auto MDI/MDI-X), Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Quality of Service (QoS), Device Link Detection Protocol (DLDP) support, Endpoint Admission Defense (EAD), STP Root Guard, LLDP support, Link Aggregation Control Protocol (LACP), Port Security, Management Information Base (MIB), dynamic ARP protection, DHCP protection, 500KB packet buffer, non blocking ports, Ingress Layer 2 MAC Access Control Lists (ACLs), Strict Priority (SP), Intelligent Resilient Framework Technology (IRF), Smoothed Deficit Weighted Round Robin (SDWRR), IP source guard, Bridge protocol data unit (BPDU)
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP)
PowerAC 120/230 V (50/60 Hz)
Dimensions (WxDxH)17.3 in x 6.3 in x 1.7 in
Weight6.61 lbs
Manufacturer WarrantyLimited lifetime warranty

EXTENDED SPECIFICATIONS

General
Device TypeSwitch – 24 ports – L3 – managed
Enclosure TypeRack-mountable 1U
SubtypeGigabit Ethernet
Ports24 x 10/100/1000 + 4 x Gigabit SFP
PerformanceLatency (1000Base-T): 3 ?s ? Throughput: up to 41.7 Mpps ? Routing/switching capacity: 56 Gbps
CapacityVirtual interfaces (VLANs): 4094 ? IPv4 routing table entries: 32
MAC Address Table Size8192 entries
Jumbo Frame Support10KB
Routing ProtocolOSPF, RIP, IGMP, static IPv4 routing, static IPv6 routing
Remote Management ProtocolSNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTPS, CLI
Encryption AlgorithmSSL
Authentication MethodRADIUS, Secure Shell v.2 (SSH2), HWTACACS
FeaturesFlow control, DHCP support, VLAN support, auto-uplink (auto MDI/MDI-X), Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Quality of Service (QoS), Device Link Detection Protocol (DLDP) support, Endpoint Admission Defense (EAD), STP Root Guard, LLDP support, Link Aggregation Control Protocol (LACP), Port Security, Management Information Base (MIB), dynamic ARP protection, DHCP protection, 500KB packet buffer, non blocking ports, Ingress Layer 2 MAC Access Control Lists (ACLs), Strict Priority (SP), Intelligent Resilient Framework Technology (IRF), Smoothed Deficit Weighted Round Robin (SDWRR), IP source guard, Bridge protocol data unit (BPDU)
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP)
RAM128 MB SDRAM
Flash Memory128 MB
Status IndicatorsPower
Expansion / Connectivity
Interfaces24 x 1000Base-T RJ-45 ? 4 x Gigabit LAN SFP ? 1 x console RJ-45 management
Power
Power DeviceInternal power supply
Voltage RequiredAC 120/230 V (50/60 Hz)
Miscellaneous
Rack Mounting KitIncluded
Compliant StandardsETSI, CISPR 22 Class A, GOST, EN 61000-3-2, NOM, EN 61000-3-3, EN55022 Class A, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, FCC Part 15 A, ANATEL, FDA, EN 60825-1, ANSI C63.4-2003, EN 60825-2, EN 61000-3-2:2006, VCCI Class A, EN 61000-3-3:1995+A1:2001+A2:2005, AS/NZS CISPR 22, EMC 2004/108/EC, EN 300 386 V1.3.3, FCC CFR47 Part 15 A, CAN/CSA-C22.2 No. 60950-1
Dimensions & Weight
Width17.3 in
Depth6.3 in
Height1.7 in
Weight6.61 lbs
Manufacturer Warranty
Service & SupportLimited warranty – lifetime
Environmental Parameters
Min Operating Temperature32 ?F
Max Operating Temperature113 ?F
Humidity Range Operating10 – 90% (non-condensing)
Min Storage Temperature-40 ?F
Max Storage Temperature158 ?F
Humidity Range Storage5 – 95% (non-condensing)

?

Weight and dimensions for JE074B?
Weight7 lbs
SKU

JE074B

Condition

New

Brand

HPE

GTIN

0 889894168733

Warranty for JE074B?
  • The warranty for refurbished units is 30 days.
  • The warranty for New units is as per the manufacturer’s terms and conditions.
