JG875A – HPE MSR1002-4 – Router – 4-port switch – GigE – rack-mountable.

HPE MSR1002-4 – Router – 4-port switch – GigE – rack-mountableThe HPEFlexNetwork MSR1000 Router Series delivers high-performance, small branch routing up to 500 Kpps in a cost-optimized modular form factor. Featuring integrated routing, switching, security, and SIP with no additional licensing, you can boost your service delivery while simplifying the management of your corporate WAN. With Comware v7 and a convenient modular design, the MSR1000 brings enhanced performance and advanced services, as well as a choice of connectivity options to provide flexible, open standards and lasting investment protection with lower CAPEX and OPEX for small-sized branches.WHAT’S IN THE BOX – (1) HPEMSR1002-4 AC RouterReduces Complexity and Simplifies Your NetworkThe HPEFlexNetwork MSR1000 Router Series simplifies your network through integrated routing, switching, security, and voice, and combines the flexibility of modular upgrades to deliver high-performance small branch routing. Makes administration easier with HPEIntelligent Management Center (IMC) Software. Reduces management complexity with zero-touch deployment (ZTP) and Dynamic VPN.Enhances Time to Service and Branch PerformanceThe HPEFlexNetwork MSR1000 Router Series offers high performance routing with up to 500 Kpps forwarding and 170 Mbps of IPSec encryption throughput to meet bandwidth requirements of branch traffic. Supports branch requirements with a comprehensive feature set to improve service delivery. Eases the transition to the cloud with integrated security.Increases Your Return on Your InvestmentThe HPEFlexNetwork MSR1000 Router Series is a compact modular platform with a wide range of connectivity options that enables the right design for your needs. Reduces your TCO through open standards, power and space savings, and energy-efficient hardware. Deploy advanced features with no additional licensing.Boosts Agility and ResiliencyThe HPEFlexNetwork MSR1000 Router Series provides branch service and business continuity with 4G/LTE and 3G WAN. Gives you an open standards approach to your network infrastructure. With advanced hardware architecture, you get reliable, high-performance functionality with multi-core processors.

MAIN SPECIFICATIONS
Product Description	HPEMSR1002-4 – router – desktop, rack-mountable
Device Type	Router – 4-port switch (integrated)
Enclosure Type	Desktop, rack-mountable – 1U
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Performance	Throughput: 500 Kpps
Capacity	IPv4 routing table entries: 200000 ? IPv4 forwarding table entries: 1000 ? IPv6 routing table entries: 200000 ? IPv6 forwarding table entries: 200000
Network / Transport Protocol	TCP/IP, L2TP, RSVP, NTP, PPPoE
Routing Protocol	OSPF, BGP-4, IS-IS, RIP-1, RIP-2, IGMPv2, VRRP, OSPFv2, PIM-SM, PIM-DM, IGMPv3, GRE, OSPFv3, Multiprotocol BGP, MSDP, static IPv4 routing, static IPv6 routing, RIPng
Remote Management Protocol	SNMP 1, SNMP 2, RMON 1, Telnet, SNMP 3, HTTP, SSH, CLI
Features	Weighted Fair Queuing (WFQ), Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping
Compliant Standards	IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
Power	AC 120/230 V (50/60 Hz)
Dimensions (WxDxH)	14.2 in x 11.8 in x 1.7 in
Weight	6.83 lbs
EXTENDED SPECIFICATIONS
General
Device Type	Router – 4-port switch (integrated)
Enclosure Type	Desktop, rack-mountable – 1U
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Performance	Throughput: 500 Kpps
Capacity	IPv4 routing table entries: 200000 ? IPv4 forwarding table entries: 1000 ? IPv6 routing table entries: 200000 ? IPv6 forwarding table entries: 200000
Network / Transport Protocol	TCP/IP, L2TP, RSVP, NTP, PPPoE
Routing Protocol	OSPF, BGP-4, IS-IS, RIP-1, RIP-2, IGMPv2, VRRP, OSPFv2, PIM-SM, PIM-DM, IGMPv3, GRE, OSPFv3, Multiprotocol BGP, MSDP, static IPv4 routing, static IPv6 routing, RIPng
Remote Management Protocol	SNMP 1, SNMP 2, RMON 1, Telnet, SNMP 3, HTTP, SSH, CLI
Encryption Algorithm	MD5, TLS
Authentication Method	RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP)
Features	Weighted Fair Queuing (WFQ), Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping
Compliant Standards	IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, EN55022 Class B, ICES-003 Class B, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 61000-4-8, ANSI C63.4-2003, EN 61000-3-2:2006, EN 61000-3-3:1995+A1:2001+A2:2005, EN 61000-4-11:2004, EN 55024:1998+A1:2001+A2:2003
Processor	1 x 667 MHz
RAM	512 MB DDR3 SDRAM
Flash Memory	256 MB
Expansion / Connectivity
Interfaces	LAN: 4 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ? WAN: 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ? Management: 1 x RJ-45 ? USB 2.0: 1 x ? LAN: 1 x Ethernet 1000 – SFP (mini-GBIC)
Expansion Slots	2 (total) / 2 (free) x Smart Interface Card (SIC) ? 1 (total) / 1 (free) x Double Smart Interface Card (DSIC)
Power
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Power Consumption Operational	30 Watt
Miscellaneous
Rack Mounting Kit	Included
Dimensions & Weight
Width	14.2 in
Depth	11.8 in
Height	1.7 in
Weight	6.83 lbs
Environmental Parameters
Min Operating Temperature	32 ?F
Max Operating Temperature	113 ?F
Humidity Range Operating	5 – 95% (non-condensing)
