WS-C3850-48F-S CISCO Catalyst 3850 48 Ports Manageable Layer 2 Network Switch

Part#: WS-C3850-48F-SEAN: 882658 547874Condition: Refurbished

Price of WS-C3850-48F-S-REFURBISHED

$296.00

With free ground shipping to USA

Stock: 4 units available

Our Shipping Partners

5-7 Business Days Standard Shipping

100% Secure Payments

Payments processed via STRIPE

Secure Payments

Pay Securely

Fast Shipping

Overnight Available

Save Big

Affordable Prices

9-5 Support

Call Us for Help

Product Details

Cisco Catalyst WS-C3850-48F-S – Switch – L3 – managed – 48 x 10/100/100(PoE+) – desktop, rack-mountable – PoE+ (80W)

The Cisco Catalyst 385series is the enterprise-class stackable access-layer switch that provides full convergence between wired and wireless on a single platform. Cisco’s Unified Access Data Plane (UADP) application-specific integrated circuit (ASIC) powers the switch and enables uniform wired-wireless policy enforcement, application visibility, flexibility, and application optimization. The Cisco Catalyst 385series switches support full IEEE 802.3at Power over Ethernet Plus (PoE+), modular and field-replaceable network modules, redundant fans, and power supplies.

What are Key Selling Points for WS-C3850-48F-S

Converged wired plus wireless access
Flexible NetFlow (FNF)
Advanced wired plus wireless QoS capabilities
Provides a rich set of security features

What transceiver modules work with WS-C3850-48F-S? (click on part number to go their product page)

SFP-10G-SR	SFP-10G-BXU-I	SFP-10G-AOC3M
SFP-10G-SR-S	SFP-10G-BX40D-I	SFP-10G-AOC5M
SFP-10G-LRM	SFP-10G-BX40U-I	SFP-10G-AOC7M
SFP-10G-LR	SFP-H10GB-CU1M	SFP-10G-AOC10M
SFP-10G-LR-S	SFP-H10GB-CU3M	DWDM-SFP10G-XX.XX
SFP-10G-ER	SFP-H10GB-CU5M	CWDM-SFP10G-XXXX
SFP-10G-ER-S	SFP-H10GB-ACU7M	SFP-H10GB-CU1-5M
SFP-10G-ZR	SFP-H10GB-ACU10M	SFP-H10GB-CU2M
SFP-10G-ZR-S	SFP-10G-AOC1M	SFP-H10GB-CU2-5M
SFP-10G-BXD-I	SFP-10G-AOC2M

Main Specifications

Product Description	Cisco Catalyst WS-C3850-48F-S – switch – 48 ports – managed – rack-mountable
Device Type	Switch – 48 ports – L3 – managed – stackable
Enclosure Type	Rack-mountable 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/100(PoE+)
Power Over Ethernet (PoE)	PoE+
PoE Budget	80W
Performance	Switching capacity: 176 Gbps – Stacking bandwidth: 48Gbps
Capacity	IPv4 routes: 2400- NetFlow entries: 4800- Switched virtual interfaces (SVIs): 1000
MAC Address Table Size	3200entries
Jumbo Frame Support	9198 bytes
Routing Protocol	RIP-1, RIP-2, EIGRP, RIPng
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, SSH, CLI
Features	Auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, IPv6 support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, Virtual Route Forwarding-Lite (VRF-Lite), MLD snooping, Dynamic ARP Inspection (DAI), PoE+, STP Root Guard, Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4 support, Shaped Round Robin (SRR), Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN), layer 3 load balancing, Energy Efficient Ethernet, Cisco StackWise-48technology, Cisco StackPower technology, Flexible NetFlow (FNF)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at
Power	AC 120/23V (50/6Hz)
Power Redundancy	Optional
Dimensions (WxDxH)	17.5 in x 18.9 in x 1.8 in
Weight	17.64 lbs
Manufacturer Warranty	Limited lifetime warranty

Extended Specifications

General

Device Type	Switch – 48 ports – L3 – managed – stackable
Enclosure Type	Desktop, rack-mountable 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/100(PoE+)
Power Over Ethernet (PoE)	PoE+
PoE Budget	80W
Performance	Switching capacity: 176 Gbps – Stacking bandwidth: 48Gbps
Capacity	IPv4 routes: 2400- NetFlow entries: 4800- Switched virtual interfaces (SVIs): 1000
MAC Address Table Size	3200entries
Jumbo Frame Support	9198 bytes
Routing Protocol	RIP-1, RIP-2, EIGRP, RIPng
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, SSH, CLI
Authentication Method	Kerberos, Secure Shell (SSH), RADIUS, TACACS+
Features	Auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, IPv6 support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, Virtual Route Forwarding-Lite (VRF-Lite), MLD snooping, Dynamic ARP Inspection (DAI), PoE+, STP Root Guard, Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4 support, Shaped Round Robin (SRR), Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN), layer 3 load balancing, Energy Efficient Ethernet, Cisco StackWise-48technology, Cisco StackPower technology, Flexible NetFlow (FNF)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at
RAM	4 GB
Flash Memory	2 GB
Status Indicators	Port transmission speed, port duplex mode, system, status, PoE

Expansion / Connectivity

Interfaces	48 x 10Base-T/100Base-TX/1000Base-T – RJ-45 PoE+ – 3W – 1 x USB Type A – 1 x console – mini-USB Type B management – 1 x RS-232 – RJ-45 management – 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 management – 2 x network stack device
Expansion Slots	1 (total) / 1 (free) x expansion slot

Power

Power Device	Internal power supply
Installed Qty	1 (installed) / 2 (max)
Power Redundancy	Optional
Power Redundancy Scheme	1+1 (with optional power supply)
Power Provided	110Watt
Voltage Required	AC 120/23V (50/6Hz)

Miscellaneous

MTBF	241,05hours
Compliant Standards	CISPR 22 Class A, GOST, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, NOM, EN 61000-3-3, EN55024, ICES-003 Class A, RoHS, UL 60950-1 Second Edition, KCC, FCC Part 15 A, ISO 7779, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class A, EN 55022 Class A

Software / System Requirements

Software Included

Cisco IOS IP Base

Dimensions & Weight

Width	17.5 in
Depth	18.9 in
Height	1.8 in
Weight	17.64 lbs

Manufacturer Warranty

Service & Support

Limited warranty – advance parts replacement – lifetime – response time: next business day – Technical support – consulting – 9days

Environmental Parameters

Min Operating Temperature	23 Degree Fahrenheit
Max Operating Temperature	113 Degree Fahrenheit
Humidity Range Operating	1- 95% (non-condensing)
Min Storage Temperature	-4Degree Fahrenheit
Max Storage Temperature	158 Degree Fahrenheit
